4 Kelvin Closed Cycle Refrigerator Systems from Janis and SHI
Sumitomo (SHI) 4 K Refrigerator - RDK-408D2 (1 Watt @ 4.2 K)
Overview
These systems provide 1.0 Watt of cooling at a temperature of 4.2 K at the second stage, and can reach a minimum temperature of 3 K (with no parasitic or experimental heat loads). Compact water- or air-cooled compressors and 6-meter long flexible gas lines complete the refrigerator package. (Please see our Compressors page for more information.) Designs incorporating both refrigerator and cryostat are available for a variety of applications.
Standard Configuration
These systems provide 1.0 Watt of cooling at a temperature of 4.2 K at the second stage, and can reach a minimum temperature of 3 K (with no parasitic or experimental heat loads). Compact water- or air-cooled compressors and 6-meter long flexible gas lines complete the refrigerator package. (Please see our Compressors page for more information.) Designs incorporating both refrigerator and cryostat are available for a variety of applications.
Characteristics:
- Refrigeration Capacity 1W @ 4.2 K
- Orientation Independent
- Push-button Operation
Please click here to download the RDK-408D2 drawing and typical load map (252 KB).
The downloaded file will be in PDF format which is viewable and printable with Acrobat Reader, a free plug-in utility from Adobe. To download the free acrobat plug-in software click here.
Click here to contact Janis today!
Specifications
COLD HEAD MODEL RDK-408D2
| Refrigeration Cycle | Modified Gifford-McMahon |
Refrigeration Capacity
(Vertical Position) | 50/60 Hz | 1st stage: 40/50 W @ 43 K
2nd stage: 1.0 W @ 4.2 K |
| Orientation | Any - Capacity Loss: Max 15% |
| Weight | Approximately 18 kg |
| Dimension | 180W x 294L x 557H (mm) |
| Maintenance Interval | 10,000 Hours |
| Flexline Length | 6m |
| Flexline Weight | 5 kg per line |
| Compatible Compressor Unit Model | CSA-71A, F-70L, F-70H |
Specifications subject to change without notice.
